| Capacity(VA) |
1KVA12V |
1.3KVA12V |
1.5KVA12V |
2KVA24V |
3KVA24V |
3.8KVA24V |
5KVA48V |
6.3KVA48V |
8KVA48V |
10KVA48V |
12.5KVA48V |
| MODEL |
NEX1020MP |
NEX1312MP |
NEX1512MP |
NEX1624MP |
NEX2424MP |
NEX3024MP |
NEX4048MP |
NEX5048MP |
NEX6448MP |
NEX8048MP |
NEX10048MP |
| Input |
| Voltage(DC) |
12V |
24V/48V |
48V |
| Nominal Voltage |
220VAC(Standard) /110VAC (Custom) |
| Voltage Range |
154-265VAC ;185-264VAC ( selectable) |
| Frequency |
50-60HZ Auto sensing |
| Output |
| Walt |
800W |
1000W |
1200W |
1600W |
2400W |
3000W |
4000W |
5000W |
6400W |
8000W |
10KW |
| Voltage |
220VAC±10% (110VAC±10%) |
| Frequency |
50/60HZ |
| Waveform |
Pure Sine Wave |
| Transfer Time (AC to DC) |
<8ms |
| Transfer Time (DC to AC) |
<8ms |
| Output Voltage Regulation |
土10% |
| Bypass Mode |
Yes |
| Saver Mode |
Yes |
| Efficiency |
>98% |
| Protection |
| Input Protection |
Circuit Breaker |
| Output Protection |
Circuit Breaker |
| Battery |
|
| Battery Type |
AGM-Deep Cycle,GEL,LIFEP04 |
| UP to 500Ah |
| Charging Current |
20A |
25a |
30A |
15A |
30A |
35A |
20A |
29A |
39A |
50A |
60A |
| Low Level disconnect (Selectable) |
10V or 10.5V |
24V：20V or 21V
48V：40V or 42V |
| LCD indicator status |
Input AC,Output AC |
| Battery DC,Output Load |
| Alarm,Fault |
| Battery Charge Level |
| Output Frequency |
| LED indicator status |
AC Line In:Green |
| Inverter:Green |
| Charging :Yellow |
| Alarm :Red |
| Battery low alarm |
12V:battery light discharge11.5V;battery load discharge 11.5V@load<20%;
11V@load>50%/10.5V@load>50%;
24V:battery light discharge23V;battery load discharge 23V@load<20%;
22V@load>50%/21V@load>50%;
48V:battery light discharge46V;battery load discharge 46V@load<20%;
44V@load>50%/42V@load>50%; |
| Battery low recovery |
12V:battery light discharge12V;battery load discharge 12V@load<20%;
11.5V@load>50%/11V@load>50%;
24V:battery light discharge24V;battery load discharge 24V@load<20%;
23V@load>50%/22V@load>50%;
48V:battery light discharge48V;battery load discharge 48V@load<20%;
46V@load>50%/44V@load>50%; |
| DC low voltage shutdown |
12V:battery light discharge11V;battery load discharge 11V@load<20%;
10.5V@load>50%/10V@load>50%;
24V:battery light discharge22V;battery load discharge 22V@load<20%;
21V@load>50%/20V@load>50%;
48V:battery light discharge44V;battery load discharge 44V@load<20%;
42V@load>50%/40V@load>50%; |
| DC high voltage alarm and fault |
16V |
32V |
64V |
| DC high voltage recovery |
15V |
30V |
60V |
| Maximum PV array power |
800W |
1600W |
3200W |
| MPPT/PWM input voltage range |
MPPT:15-150VDC
PWM:15-50VDC |
MPPT:30-150VDC
PWM:30-105VDC |
MPPT:60-150VDC
PWM:60-105VDC |
| Maximum PV array open circuit voltage |
MPPT:150VDC
PWM:50VDC |
MPPT:150VDC
PWM:105VDC |
MPPT:150VDC
PWM:105VDC |
| Maximum solar charging current |
60A |
120A |
| Alarm |
| Low battery alarm |
Audible alarm-1 beeping per second |
| Overload alarm |
Audible alarm-continuous beeping |
| Fault |
Audible alarm-continuous beeping |
| Environment |
| Temperature |
-10~50℃ |
| Humidity |
C0-95%,Non condensing |
| Accoustic Noise(db) |
<45db |
